LPCW150 Fixed Window Wall

Product Summary

The LPCW150 Fixed Window Wall System is a high-performance glazing solution designed for large openings and expansive views. With a sleek, modern profile and a high glass-to-frame ratio, it maximizes natural light while delivering dependable energy efficiency.

NFRC-certified performance options include U-factors as low as 0.20, low solar heat gain values, and excellent condensation resistance. The system supports both double- and triple-glazed Low-E insulated glass with argon fill, allowing flexibility to meet climate and design requirements.

Ideal for residential, multi-family, and light commercial applications, the LPCW150 offers a refined aesthetic with verified performance for today’s architectural demands.

Specifications

The following data is based on a test triple paned window of the size 47.25"x 59.06" (1200mmx1500m).

Technical Data

Frame / Sash: Aluminum (Fixed / Non-operable)
Glazing Configuration: Triple-glazed insulated glass unit (IGU)
Glass Thickness: 6 mm / 6 mm / 6 mm
Overall IGU Thickness: 1-5/8" (≈41 mm)
Coatings: dual low-E coating
Spacer Type: Thermally improved spacer (TS-D)
Gas Fill: Argon (95%) — both cavities
Tint: Clear

Performance Data

Thermal Insulation (U-Value): 0.22 BTU/hr·ft²·°F
Solar Heat Gain Coefficient (SHGC): 0.27
Visible Transmittance (VT): 0.45
Condensation Resistance (CR): 73
